Hardware Inventory and Visualization in the Server Room: Deploying Rackula on Docker

1. Diagnosis: why your rack diagram in Excel always lies

You rack a new server. Slot it into the third unit from the top. Forget to update the spreadsheet. Six months later, someone other than the person who maintained that spreadsheet looks at it, and sees something completely different from what’s actually in the rack.

Sound familiar? Hardware inventory in a server room usually lives in one of three states: a paper label on the cabinet door, an Excel file on a shared drive that nobody has opened in a year, or a Visio diagram drawn once before an audit and forgotten right after.

All three break for the same reason: updating the diagram isn’t built into the process of installing hardware. You rack a server, then go configure the OS, not open a diagram editor.

Rackula solves this differently. You don’t draw the diagram ahead of time and reconcile it manually later. You drag the device block onto the right unit with your mouse, right while you’re planning the install, and the diagram immediately becomes live documentation instead of an archival artifact.

By the end of this article you’ll have:

• Rackula deployed in Docker with persistent data storage (persist mode)
• An understanding of the difference between client-side and server-side storage modes
• A working rack diagram with IP addresses and notes for each device
• A reverse proxy configured for access from your local network
• A list of five typical failures and commands for diagnosing them
• A backup scheme for your rack data
• An understanding of when Rackula isn’t the right fit, and what to use instead

This takes about twenty minutes of active time, not counting log reading on your first permissions mess. And there will be one, more on that below in the complications section.

2. Root causes: why manual rack inventory doesn’t work

Let’s break down exactly what breaks rack hardware tracking when you do it manually.

That last point is the most common. You open the spreadsheet, see a list of forty text rows, and still go physically count free units in the rack by hand. The whole point of documentation is lost.

3. The fix: deploying Rackula with persistent data

Prerequisites

You need Docker Engine and Docker Compose v2 on the host. Check versions before you start:

docker --version
docker compose version

Rackula ships in two image modes. The latest tag is a pure frontend, everything is stored in the browser via localStorage, data doesn’t survive a change of computer. The persist tag is the frontend plus a separate rackula-api container that writes YAML files to the host disk. For hardware inventory that the whole team looks at, only persist mode works. Client mode is for sketching a quick diagram and nothing more.

mkdir -p /opt/docker/rackula/data
cd /opt/docker/rackula
chown -R 1001:1001 data

Step 1. Docker Compose file

Create docker-compose.yml. Below is a working setup with resource limits and basic hardening, no reverse proxy yet, just for testing on a local port.

services:
  rackula:
    image: ghcr.io/rackulalives/rackula:persist
    container_name: rackula
    ports:
      - "8080:8080"
    environment:
      - API_HOST=rackula-api
      - API_PORT=${RACKULA_API_PORT:-3001}
      - RACKULA_LISTEN_PORT=8080
      - API_WRITE_TOKEN=${RACKULA_API_WRITE_TOKEN:-}
      - RACKULA_AUTH_MODE=none
    restart: unless-stopped
    stop_grace_period: 10s
    depends_on:
      rackula-api:
        condition: service_healthy
    networks:
      - rackula-network
    deploy:
      resources:
        limits:
          cpus: "0.50"
          memory: 128M
        reservations:
          cpus: "0.10"
          memory: 16M
    security_opt:
      - no-new-privileges:true
    cap_drop:
      - ALL
    read_only: true
    tmpfs:
      - /var/cache/nginx:size=10M
      - /var/run:size=1M
      - /tmp:size=5M
      - /etc/nginx/conf.d:size=1M,uid=101,gid=101

  rackula-api:
    image: ghcr.io/rackulalives/rackula-api:latest
    container_name: rackula-api
    restart: unless-stopped
    stop_grace_period: 10s
    volumes:
      - ./data:/data
    networks:
      - rackula-network
    environment:
      - DATA_DIR=/data
      - RACKULA_API_PORT=${RACKULA_API_PORT:-3001}
      - CORS_ORIGIN=${CORS_ORIGIN:-http://localhost:8080}
      - RACKULA_API_WRITE_TOKEN=${RACKULA_API_WRITE_TOKEN:-}
      - RACKULA_AUTH_MODE=none
      - RACKULA_AUTH_SESSION_COOKIE_SECURE=false
      - RACKULA_AUTH_CSRF_PROTECTION=true
      - ALLOW_INSECURE_CORS=false
    deploy:
      resources:
        limits:
          cpus: "0.25"
          memory: 128M
        reservations:
          cpus: "0.05"
          memory: 32M
    security_opt:
      - no-new-privileges:true
    cap_drop:
      - ALL
    read_only: true
    tmpfs:
      - /tmp:size=5M
    healthcheck:
      test: ["CMD-SHELL", "wget -qO- http://127.0.0.1:${RACKULA_API_PORT:-3001}/health"]
      interval: 30s
      timeout: 10s
      start_period: 5s
      retries: 3

networks:
  rackula-network:
    name: rackula-network
    driver: bridge

Pay attention to the memory limit on rackula-api. The original examples in the docs set 64M, in practice that’s not enough, the container dies with OOM exit code 137 on the very first device library import. Set 128M right away, it’ll save you an evening of log diving.

Step 2. Environment variables file

RACKULA_API_WRITE_TOKEN=generate_a_random_32_char_string
CORS_ORIGIN=http://YOUR_HOST_IP:8080

CORS_ORIGIN must match, character for character, the address you use to open the interface in your browser. If the protocol or port doesn’t match, you’ll get a silent write failure with no clear error on screen.

Step 3. Startup

docker compose up -d
docker compose logs -f

Result: both containers in running status, rackula-api healthy. The rackula-api logs shouldn’t contain any permission denied lines for writes to /data.

Step 4. Reverse proxy

Don’t expose port 8080 directly to the internet, Rackula has no built-in brute-force protection unless you set up OIDC. It makes more sense to put the service behind your usual reverse proxy with basic auth or behind an SSO portal. Example for nginx:

server {
    listen 443 ssl http2;
    server_name rackula.example.local;

    ssl_certificate     /etc/nginx/ssl/fullchain.pem;
    ssl_certificate_key /etc/nginx/ssl/privkey.pem;

    location / {
        proxy_pass http://127.0.0.1:8080;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
    }
}

After publishing over HTTPS, don’t forget to change CORS_ORIGIN to the new address and enable RACKULA_AUTH_SESSION_COOKIE_SECURE.

Deployment architecture

4. Verification: is the inventory working correctly

After starting the stack, check three things in order: container status, API health, and status in the interface itself.

docker compose ps

Both services should be Up, rackula-api should be Up (healthy). Next, check the health endpoint directly:

curl -s http://127.0.0.1:3001/health

Open the web interface in a browser. The top right corner should say Online, not Offline. Create a test rack, drag one device block, refresh the page. If the block stays in place after the refresh, saving in persist mode is working.

The last test: save your data, stop the stack completely, and bring it back up:

docker compose down
docker compose up -d

The rack should appear right where it was as soon as the page loads, no manual file import needed. That’s the difference between persist mode and regular client-side mode.

5. Complications: what breaks most often

Usually this is where people write “don’t worry, it’s not that scary.” I won’t lie: almost everyone trips over permissions on the first run. The good news is it’s fixed with a single command.

6. Alternatives: when Rackula isn’t the right fit

Rackula isn’t the only option for server room hardware inventory, and not always the best one. Here’s what you should actually compare it against.

The case for Rackula in this article is simple: the barrier to entry is lower than NetBox’s, and the output is visual, not just tabular. If you need a full CMDB with Ansible inventory integration, go straight to NetBox, don’t waste time on a halfway solution.

7. Prevention: don’t lose your rack data

Rackula’s data in persist mode is just YAML files in the data directory. That means backing it up is as simple as backing up any config.

borg create --stats /path/to/repo::rackula-{now} /opt/docker/rackula/data

One lost data folder without a backup isn’t a disaster, it’s just an evening spent rebuilding the diagram from memory and old screenshots in your Telegram chat.

For auto-start after a host reboot, the unless-stopped restart policy in docker-compose.yml already covers that, nothing extra needed. For availability monitoring, add an HTTP status check on port 8080 to your monitoring system, whether that’s Zabbix or something simpler.

8. FAQ: common questions about rack hardware inventory

Why doesn’t saving a rack work after setting up Rackula?
Most often it’s permissions on the data directory, the rackula-api container writes as UID 1001, but the directory was created by root. Change the owner with chown and restart the container.

How do I check that Rackula is working correctly?
Three checks in a row: docker compose ps container status, the /health endpoint on the API port, and the Online status in the top right corner of the interface after loading the page.

What do I do if rackula-api keeps crashing?
Check the container’s exit code. Code 137 means OOM Kill, the container doesn’t have enough memory for the limit set in docker-compose.yml. Raise the memory limit to 128M or higher.

How is Rackula different from NetBox for server room inventory?
Rackula is about a visual rack diagram and physical layout, deployable in 15 minutes. NetBox is a full CMDB with IPAM, cable tracking, and Ansible integration, but it takes considerably more time to set up and requires understanding its data schema.

9. What to expect

After this setup you have Rackula running in persist mode, data written to YAML on the host disk instead of living only in one engineer’s browser. The rack diagram updates right at the moment hardware gets installed, instead of turning into a separate “someday” task.

From here it’s a matter of habit. Make it a rule: rack a unit, immediately drag the block into Rackula, before you go configure the OS. In a month, the rack diagram will be more accurate than any spreadsheet the whole team maintained for six months. If after setup the status still shows offline or the container keeps crashing for reasons other than the ones described above, leave a comment and we’ll sort it out.

System requirements

At the time of publication, the image tags above are current. Before installing, check the latest releases in the project’s GitHub Releases, versions come out frequently, and the changelog sometimes requires manual action on update (for example, the OIDC redirect URI change in one release).

Port table

Security

• Never expose port 3001 externally under any circumstances, it’s direct access to write operations
• Block port 8080 on the host firewall, publish only through a reverse proxy with TLS
• Use RACKULA_API_WRITE_TOKEN, without a token, writes are open to anyone who can reach the API
• If your rack data is sensitive, put basic auth on the reverse proxy or set up OIDC through an SSO provider
• Keep RACKULA_AUTH_SESSION_COOKIE_SECURE=true when running over HTTPS, otherwise the session cookie goes out in plain text
• The containers already run with read_only and cap_drop ALL in the example compose file, don’t remove these options without good reason

Updating

Always read the release changelog before updating, Rackula moves fast, and some changes require editing .env, as happened with the OIDC redirect URI.

docker compose pull
docker compose up -d
docker compose logs -f rackula-api

To roll back, pin a specific previous release tag in docker-compose.yml instead of latest, and bring the stack back up, the data in the data directory stays untouched, the diagram stays right where it was.
